An RBA (Rebuildable Atomizer)
is a type of atomizer used in vaping devices that allows users to build their
own coils. This is also the component
that heats the e-liquid to the point of vaporization. The term “rebuildable” refers to
the fact that users can assemble the wicking material and coil themselves
rather than using pre-made coil heads. Using
RBAs requires some knowledge of Ohm’s law and battery safety, as the resistance
of the coils must be compatible with the power output of the battery. Users also need to ensure that the coils are
properly secured and that the wicking material is correctly installed to
prevent dry hits and leaking, more on that in a little bit.
Now, with all that being said, although enthusiasts
enjoy RBAs because they offer the ability to fine-tune their vaping experience,
and they can be more cost-effective in the long run since pre-made coils are
not required, issues can still arise.
You see, a rebuildable atomizer can sometimes malfunction due to various
reasons: dirty contacts, damaged coils, poor wicking, or damaged insulators. And, that’s why we are going to cover some
general tips for common problems you might experience with your RBA.
How Can a Rebuildable Atomizer Break?
First, we do need to cover some the key reasons why an
RBA might break or stop functioning correctly:
1.Improper Coil Installation:
If the coil is not installed correctly, it might cause a short circuit or not
produce any vapor at all. A coil that touches the deck or sides of the atomizer
can result in a short.
2.Over-tightening:
Whether it’s the posts screws, the RBA sections, or the tank itself,
over-tightening can strip the threading or break parts.
3.Poor Quality Materials:
RBAs made from cheap materials might degrade or break more quickly than those
made from high-quality materials.
4.Excessive Dry Burning:
Dry burning a coil to clean it or check for hot spots can weaken the wire over
time, especially if done excessively or at very high wattages.
5.Wear and Tear:
Like any device, with regular usage, the components of an RBA can wear out.
O-rings can degrade, threading can wear, and screws can become stripped.
6.Accidental Damage:
Dropping or knocking the RBA can cause damage, like cracking the tank, damaging
the posts, or misaligning parts.
7.Liquid Leakage:
If e-liquid leaks into areas it shouldn’t, it can cause short circuits or other
malfunctions.
8.Corrosion:
Some e-liquids, especially those that are acidic, can corrode the metal parts
of an RBA over time.
9.Electrical Issues:
Faulty connections, damaged insulators, or other electrical issues can cause
the RBA to malfunction.
10.Inadequate Maintenance:
Not cleaning the RBA regularly can lead to build-up, which might cause poor
performance or breakage.
11.Mismatched Components:
Using parts from different RBAs or non-compatible parts can cause issues.
12.Inadequate Wicking:
Incorrect wicking can lead to dry hits, hotspots, or even damage to the RBA if
it causes consistent overheating.
How to Fix an RBA
If you’re having trouble with your RBA, here’s a
step-by-step guide to help you fix the issue:
1.Safety
First:
- Always make sure to turn off your mod
or remove the batteries before working on your RBA. - Avoid short circuits by ensuring all
components are correctly installed and there’s no contact between the coil
and the build deck, except at the posts.
2.Disassemble
and Clean:
- Take apart the RBA, removing the drip
tip, top cap, chimney, tank (if it’s an RTA), build deck, and base. - Clean all parts using warm water and
a bit of dish soap. An old
toothbrush can be handy for scrubbing. For deeper cleaning, you can soak parts
in isopropyl alcohol or vodka, but always rinse and dry thoroughly after. - Inspect all parts for any visible
damage.
3.Check
the Coil:
- Inspect the coil for any signs of
wear, burn marks, or deformity. - If the coil looks damaged or it’s
been in use for a while, consider replacing it. - Ensure the coil legs are secured
tightly in the post holes/screws. - Make sure the coil is not touching
the build deck or any part of the atomizer, except where it should be (at
the posts). This can cause a short
circuit.
4.Re-wick
Properly:
- Ensure that your wick is neither too
thick nor too thin for the coil. - It should slide through the coil with
a slight resistance but shouldn’t deform the coil shape. - For RTAs, make sure the wick ends are
correctly placed so they can absorb juice efficiently without causing
leaks or dry hits.
5.Check
the Insulators:
- Insulators are typically made of a
plastic-like material and can be found around the positive post and
sometimes at the base of the 510 connection. - Inspect them for any signs of melting
or damage. Replace if necessary.
6.Ensure
Proper Connection:
- Ensure the 510 pin at the base of
your RBA is making proper contact with the mod. Some 510 pins are
adjustable. - If you have an adjustable 510 pin,
make sure it’s not screwed in too tight or too loose.
7.Check
for Loose Parts:
- Screws and other small parts can
sometimes become loose. Ensure
everything is appropriately tightened (but not over-tightened to avoid
stripping threads).
8.Assemble
and Test:
- Reassemble your RBA and ensure all
parts fit snugly. - Before filling with e-liquid, do a
dry fire (a brief press of the fire button) to ensure the coil heats
evenly from the center outwards without hotspots. Adjust the coil or wick
as needed. - Once satisfied, saturate the wick
with e-liquid, assemble the rest of the atomizer, and fill the tank (if
using an RTA).
9.Reconnect
to Mod and Test:
- Ensure your mod reads the coil’s
resistance correctly. - Take a few puffs to ensure there are
no dry hits, leaks, or other issues.
Note: If you’ve
followed these steps and still encounter problems, it might be time to consult
with a local vape shop or consider replacing parts or the entire RBA. Always remember to practice safety when
working with electronic devices and high-powered batteries.
There is Hope Yet to Fixing Your RBA!
Regular inspection and maintenance can significantly
increase the lifespan of your RBA and provide a better vaping experience. To avoid these issues, it’s essential to:
- Regularly
maintain and clean your RBA. - Be
gentle when assembling or disassembling. - Use
the device as per the manufacturer’s guidelines. - Replace
worn-out parts promptly. - Always
check for shorts or resistance fluctuations when installing new coils.
